Pressure switch - 1-10 Bar - 1/4" external thread - stainless-steel
Product number:
6000002
EAN:
4050571271954
Manufacturer no.:
DRS 10 ES
Weight:
0.098 kg
Length:
58.5 mm
Height:
26 mm
Width:
26 mm
Product information "Pressure switch - 1-10 Bar - 1/4" external thread - stainless-steel"
The pressure switch reacts to a pressure of 1 - 10 bar (maximum pressure can be adjusted stepless). The electrical contact is interrupted (opened) if the pressure is reached. It is a toggle pressure switch, which has the properties of an NC or an NO pressure switch, depending on the assignment (connection). Application is mainly in the ultrapure water segment (permeate), when, e.g. a tap is closed.
Technical data:
What is a pressure switch?
In our case, we are talking about pressure switches that close or open an electrical connection at a certain predefined or set pressure (in this case, water pressure).
What is an NC pressure switch?
A pressure switch that keeps a connection closed in a pressureless state and opens it only under a certain pressure is called NC or carries this designation.
NC stands for normally closed. These pressure switches are suitable for switching off, e.g. relays or pumps, when a certain pressure is reached.
What is a NO pressure switch?
A pressure switch that keeps a connection open in a pressureless state and only closes under a certain pressure is called NO or carries this designation.
NO stands for normally open. These pressure switches are suitable, for example, for detecting whether a certain pressure is present to activate something else, e.g. info LED or another process.
Technical data:
- Switch type: toggle switch
- Adjustment range: 1 to 10 bar
- Connection (for water pipe): 1/4" external thread
- Overpressure proof up to 300 bar
- Switching capacity: 4A, 250V
- Materials: body made of 1.4305 (stainless steel), seal and diaphragm made of FKM
- Temperature range: -5°C to +120°C
- Switching differential: 10 - 30 %
- Protection class: IP 65 (terminals IP 00)
- Cable connection: 6.3 mm x 0.8 mm flat plug (cable lug)
What is a pressure switch?
In our case, we are talking about pressure switches that close or open an electrical connection at a certain predefined or set pressure (in this case, water pressure).
What is an NC pressure switch?
A pressure switch that keeps a connection closed in a pressureless state and opens it only under a certain pressure is called NC or carries this designation.
NC stands for normally closed. These pressure switches are suitable for switching off, e.g. relays or pumps, when a certain pressure is reached.
What is a NO pressure switch?
A pressure switch that keeps a connection open in a pressureless state and only closes under a certain pressure is called NO or carries this designation.
NO stands for normally open. These pressure switches are suitable, for example, for detecting whether a certain pressure is present to activate something else, e.g. info LED or another process.
| Input connection: | 1/4" Außengewinde |
|---|
